CSX Motion Simulator

by **nury961** » Mon 26. Nov 2012, 15:07

Hello motiondave;

5 min ago I found only one 1 JRK from e-bay (turkey)... I paid 200 TL ( € 87,00 )...

Firstly I will do joyrider after a while when getting a little bit professional on X-sim I want to build very big motion simulator like the 360 degree 2 dof brasilian paltform..

What is your offer for motor selection, Should I use AC motor on that JRK ??? kw, rpm , torque...

by **motiondave** » Mon 26. Nov 2012, 21:58

JRKS are only 12 volts so the most used is http://www.motiondynamics.com.au/worm-d ... -180w.html , or an ebay Equivalent.
If you are going to build a big simulator like the 360 deg rolling sim, you will need big 240v motors for sure. Not sure what to use on that.

by **tronicgr** » Tue 27. Nov 2012, 02:41

nury961 wrote:What is your offer for motor selection, Should I use AC motor on that JRK ??? kw, rpm , torque...

I would really love to see that! :shock:

by **nury961** » Tue 27. Nov 2012, 11:26

tronicgr wrote:
nury961 wrote:What is your offer for motor selection, Should I use AC motor on that JRK ??? kw, rpm , torque...

I would really love to see that!

I think I am also confused about some terminologies...sorry for mentioned AC motor, but I will do another sim with AMC644 + Servo's

I selected 12VDC, 2800 rpm, 250w motor... Gearbox ratio 1:20... Any comments from sim experts???

by **motiondave** » Tue 27. Nov 2012, 22:02

nury961 wrote:
tronicgr wrote:
nury961 wrote:What is your offer for motor selection, Should I use AC motor on that JRK ??? kw, rpm , torque...

I would really love to see that!

I think I am also confused about some terminologies...sorry for mentioned AC motor, but I will do another sim with AMC644 + Servo's

I selected 12VDC, 2800 rpm, 250w motor... Gearbox ratio 1:20... Any comments from sim experts???

do you have a link for the motor? Looks good from those specs.

by **nury961** » Wed 28. Nov 2012, 11:32

250w MUGUL.pdf: (34.31 KiB) Downloaded 580 times

by **motiondave** » Wed 28. Nov 2012, 14:06

nury961 wrote:
250w MUGUL.pdf

Looks ok to me, they just need a gearbox

by **nury961** » Wed 28. Nov 2012, 14:22

motiondave wrote:
nury961 wrote:
250w MUGUL.pdf

Looks ok to me, they just need a gearbox

Gearbox 1:20 is it good enough??

by **motiondave** » Thu 29. Nov 2012, 01:36

2800 / 20 = 140 rpm. Yep, ok.

by **nury961** » Thu 29. Nov 2012, 13:43

Hi,

Today I got my pololu cards, I think I bought the last 2 cards in Turkey, because I called maybe 10 dealer but they didnt have this card, last change I bought one from a person I dont know him, and the other bought from a very small dealer and asked for anothers but he said that this was the last one...
